ASRock AB350M PRO4 Motherboard

Name: ASRock AB350M PRO4
Brand: ASRock
SKU: AB350M PRO4
Rating: 3.0 (243 reviews)

ASRock AB350M PRO4 MicroATX

★★★☆☆

(243 reviews)

Seller	Availability	Price	Shipping	Buy
Out of Stock	Out of Stock	$300.00 +Free shipping	+Free	Buy
		-	-	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.

Chipset: AMD Promontory B350
Memory: 4x DDR4-2667/2400/2133 DIMM Slots, Dual Channel, ECC, Non-ECC, Unbuffered, Max Capacity of 64GB
Slots: 2x PCI-Express 3.0 x16 Slots (one runs at x4), 1x PCI-Express 2.0 x1 Slot
SATA: 4x SATA3 Ports, Support RAID 0, 1, 10
Video: Integrated AMD Radeo R-Series Graphics in A-series APU
Supports AMD Socket AM4 A-Series APUs (Bristol Ridge) and Ryzen Series CPUs (Summit Ridge)
Supports DDR4 3200+ (OC) (Ryzen CPU) / 2400 (A-series APU)

Specifications Overview

Model	AB350M PRO4
Release Date	May 2017 * First availability for purchase, it may not correspond to the actual market launch date.
Series
Socket	AM4
Form factor	Micro ATX
Chipset	AMD B350
Supported Memory	DDR4 2133Mhz 2400Mhz 2666Mhz 2933Mhz 3200Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
Audio Chipset	Realtek ALC892
Audio Channels	7.1 Channels
LAN Chipset	Realtek 8111GR
Max LAN Speed	10/100/1000Mbps
SLI Support	No
CrossFire Support	Yes
RAID Support	Yes
Back Connect	No
Wireless LAN	No
PCI-Express x16 Slots	2
PCI-Express x4 Slots	0
PCI-Express x1 Slots	1
SATA 6 Gbps Ports	4
SATA Express Ports	0
M.2 Ports	2
M.2 Devices support	2242 / 2260 / 2280 - M Key 2230 / 2242 / 2260 / 2280 - M Key
RAM Slots	4
Maximum Supported RAM	64 GB
Onboard USB 2.0	2
Onboard USB 3.2 Gen 1	1
Onboard USB 3.2 Gen 2	0
Onboard USB 3.2 Gen 2x2	0

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C

Expert reviews

The ASRock AB350M Pro4 is available for US$74.99. Extraordinary performance for the price Easily matched neutral aesthetic Overclocking potential Underwhelming rear I/O Driver disk includes bloatware you can't directly opt out of during installation...

techPowerUp!

Read the full review
