Asus ROG Maximus XIII Extreme Motherboard

Name: Asus ROG Maximus XIII Extreme
Brand: ASUS
SKU: ROG Maximus XIII Extreme
Rating: 4.0 (1 reviews)

Asus ROG Maximus XIII Extreme (WiFi 6E) Z590 LGA 1200 PCIe 4.0 18+2 Power Stages 5X M.2 Slots 10 Gb &2.5Gb LAN Thunderbolt 4 EATX

★★★★☆

(1 reviews)

Seller	Availability	Price	Shipping	Buy
In Stock	In Stock	$588.63 +Free shipping	+Free	Buy
In Stock	In Stock	$899.99	-	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.

Intel LGA 1200 Socket: Designed To Unleash The Maximum Performance Of 11Th Gen Intel Core Processors
AI Motherboard : AI Overclocking, AI Cooling, AI Networking And AI Noise Cancelation
Extreme Power Solution: 18+2 Teamed Power Stages - Each Rated At 100 Amps, Procool II Power Connectors, Microfine Alloy Chokes And 10K Japanese-Made Black Metallic Capacitors; Unmatched Personalization: 1.77” Livedash OLED, ASUS-Exclusive Aura Sync RGB Lighting, Including RGB Headers And Gen 2 Addressable Headers; Renowned Software: Bundled 1-Year AIDA64 Extreme Subscription And Intuitive UEFI BIOS Dashboard With Integrated Memtest86
Superb Thermal Design: Enlarged VRM Heatsinks Plus Integrated Aluminum I/O Cover, High-Conductivity Thermal Pad, Five M.2 Heatsinks With Embedded Backplates And ROG Water-Cooling Zone; Industry-Leading Gaming Audio & AI Noise Cancelation: High Fidelity Audio With The Supremefx ALC4082 CODECESS, DTS Sound Unbound And Sonic Studio III Draws You Deeper Into The Game Action.Communicate Clearly With ASUS AI Noise Cancelation Technology
Future Proof Gaming Networking: Intel Wifi 6E AX210 Pair With ROG Rapture GT-AXE11000 To Enjoy World’S First 6Hgz Wireless Transfer Speed, Dual Ethernet With Marvell Aqtion 10Gb And Intel 2.5Gb Ethernet ; Fattest Gaming Connectivity: Pcie 4.0, Five M.2 Slots, USB 3.2 Gen 2X2 Front-Panel Connector, Dual Thunderbolt 4 USB-C; DIY-Friendly Design: Pre-Mounted I/O Shield, V_Latch Switch, BIOS Flashback, Q-Code, Flexkey, Q-Connector, Safeslot And Graphics Card Holder; Renowned Software: Bundled 1-Year AIDA64 Extreme Subscription And Intuitive UEFI BIOS Dashboard With Integrated Memtest86

Specifications Overview

Model	ROG Maximus XIII Extreme 90MB15S0-M0EAY0 90MB15S0-M0AAY0
Release Date	March 2021 * First availability for purchase, it may not correspond to the actual market launch date.
Series	ROG
Socket	LGA1200
Form factor	EATX
Chipset	Intel Z590
Supported Memory	DDR4 2133Mhz 2400Mhz 2666Mhz 2800Mhz 2933Mhz 3000Mhz 3200Mhz 3300Mhz 3333Mhz 3400Mhz 3466Mhz 3600Mhz 3733Mhz 3866Mhz 4000Mhz 4133Mhz 4266Mhz 4400Mhz 4500Mhz 4600Mhz 4700Mhz 4800Mhz 5000Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
Audio Chipset	ROG SupremeFX High Definition Audio CODEC ALC4082
Audio Channels	7.1 Channels
LAN Chipset	Marvell AQtion AQC113CS
Max LAN Speed	10Gbps + 10/100/1000/2500Mbps
SLI Support	Yes
CrossFire Support	No
RAID Support	Yes
Back Connect	No
Back I/O Ports	2 x Thunderbolt 4 USB Type-C port(s) 8 x USB 3.2 Gen 2 port(s) (8 x Type-A) 1 x HDMI port 1 x ASUS Wi-Fi Module 1 x Marvell AQtion AQC113CS 10Gb Ethernet 1 x Intel I225-V 2.5Gb Ethernet port 5 x LED-illuminated audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button
Wireless LAN	Yes
Wi-Fi Generation	6
PCI-Express x16 Slots	2
PCI-Express x4 Slots	1
PCI-Express x1 Slots	0
SATA 6 Gbps Ports	6
SATA Express Ports	0
M.2 Ports	5
M.2 Devices support	2242 / 2260 / 2280 - M Key 2242 / 2260 / 2280 - M Key 2242 / 2260 / 2280 - M Key (Intel 11th Gen only) 2242 / 2260 / 2280 / 22110 - M Key 2242 / 2260 / 2280 / 22110 - M Key
RAM Slots	4
Maximum Supported RAM	128 GB
Onboard USB 2.0	2
Onboard USB 3.2 Gen 1	2
Onboard USB 3.2 Gen 2	1
Onboard USB 3.2 Gen 2x2	1

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C
