Asus ROG STRIX X870E-H GAMING WIFI7 Motherboard

Name: Asus ROG STRIX X870E-H GAMING WIFI7
Brand: Asus
SKU: ROG STRIX X870E-H GAMING WIFI7
Rating: 2.0 (2 reviews)

Asus ROG STRIX X870E-H GAMING WIFI7 AM5 ATX

★★☆☆☆

(2 reviews)

Seller	Availability	Price	Shipping	Buy
In Stock	In Stock	$369.99 +Free shipping	+Free	Buy
In Stock	In Stock	$392.49	-	Buy
In Stock	In Stock	$399.99	-	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

ASUS ROG STRIX X870E-H GAMING WIFI7 AMD X870E-H ATX motherboard with 16+2+1 power stages, Dynamic OC Switcher, Core Flex, DDR5 AEMP, WiFi 7, 4x M.2, PCIe 5.0, Q-Release, dual USB4 ports and USB 10Gbps Type-C Brand: ASUS CPU Socket Type: AM5 Chipset: AMD X870E Form Factor: ATX Number of Memory Slots: 4x288pin (DDR5) Memory Standard: Supports up to 8000+MT/s(OC) with Ryzen Audio Channels: 7.1 Channels Max LAN Speed: 5Gbps

Model	ROG STRIX X870E-H GAMING WIFI7 90MB1M90-MVAAY0
Socket	AM5
Form factor	ATX
Chipset	AMD X870E
Supported Memory	DDR5 4800Mhz 8000Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
Audio Channels	7.1 Channels
Max LAN Speed	5Gbps
SLI Support	No
CrossFire Support	No
RAID Support	Yes
Back Connect	No
Back I/O Ports	2 x USB4 (40Gbps) ports(2 x USB Type-C) 4 x USB 10Gbps ports (3 x Type-A + 1 x USB Type-C with up to 30W PD/PPS Fast-charge) 6 x USB 5Gbps ports (6 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x HDMI port 1 x Wi-Fi module 1 x Realtek 5Gb Ethernet 2 x Audio jacks 1 x Optical S/PDIF out port 1 x BIOS FlashBack button 1 x Clear CMOS button
Wireless LAN	Yes
Wi-Fi Generation	7
PCI-Express x16 Slots	2
PCI-Express x4 Slots	0
PCI-Express x1 Slots	0
SATA 6 Gbps Ports	4
SATA Express Ports	0
M.2 Ports	4
M.2 Devices support	2242 / 2260 / 2280 - M Key 2280 / 22110 - M Key 2280 - M Key 2280 - M Key
RAM Slots	4
Maximum Supported RAM	256 GB
Onboard USB 2.0	2
Onboard USB 3.2 Gen 1	1
Onboard USB 3.2 Gen 2	0
Onboard USB 3.2 Gen 2x2	1

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C
