Gigabyte B860M D Motherboard

GIGABYTE B860M D Intel LGA1851 DDR5 2x M.2 PCIe 5.0 2.5GbE LAN micro ATX

Seller	Availability	Price	Shipping	Buy
In Stock	In Stock	$159.00 +Free shipping	+Free	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

Supports Intel Core Ultra 200 Series Processors 4+1+2 Phase Power Supply Design 2*DDR5 DIMM Slots, Supporting Up to 128 GB AI D5 Black Technology 2.0 Delivers Enhanced Memory Performance AI Perfdrive (CPU Black Technology): Provides users with customized BIOS preset profiles Quick and Easy Graphics Card Removal: Graphics card slot features a quick-release and tool-less design User-Friendly User Interface: Multiple themes in BIOS and software, AIO fan control, and Q-Flash

Model	B860M D
Release Date	January 2025 * First availability for purchase, it may not correspond to the actual market launch date.
Socket	LGA1851
Form factor	Micro ATX
Chipset	Intel B860
Supported Memory	DDR5 4800Mhz 8800Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
SLI Support	No
CrossFire Support	No
RAID Support	Yes
Back Connect	No
Wireless LAN	No
PCI-Express x16 Slots	1
PCI-Express x4 Slots	0
PCI-Express x1 Slots	1
SATA 6 Gbps Ports	4
SATA Express Ports	0
M.2 Ports	2
M.2 Devices support	2280 - M Key 2280 - M Key
RAM Slots	2
Maximum Supported RAM	128 GB
Onboard USB 2.0	2
Onboard USB 3.2 Gen 1	1
Onboard USB 3.2 Gen 2	0
Onboard USB 3.2 Gen 2x2	0

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C
