Gigabyte GA-AB350N-GAMING WIFI Motherboard

Name: Gigabyte GA-AB350N-GAMING WIFI
Brand: Gigabyte
SKU: GA-AB350N-Gaming WIFI
Rating: 3.0 (59 reviews)

Gigabyte GA-AB350N-Gaming WiFi AMD AM4 B350 Max.32GB DDR4 PCI Express Mini-ITX

★★★☆☆

(59 reviews)

(Change region)

Seller	Availability	Price	Shipping	Buy
		-	-	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.

Brand GIGABYTE, Model GA-AB350N-GAMING WIFI Supports AMD Ryzen & 7th Generation A-series/Athlon Processors
Dual Channel ECC/Non-ECC Unbuffered DDR4, 2 DIMMs,
Fast 2 USB 3.1 Gen 2 with USB Type-A. Smart Fan 5 features 5 Temperature Sensors and 2 Hybrid Fan Headers,
Feature Intel 802.11ac Dual Band WIFI and Bluetooth 4.2 card,
Ultra-Fast PCIe Gen3 x4 M.2 with PCIe NVMe & SATA mode support,

Specifications Overview

Model	GA-AB350N-Gaming WIFI GA-AB350N-Gaming WIFI (rev. 1.0)
Socket	AM4
Form factor	Mini ITX
Chipset	AMD B350
Supported Memory	DDR4 2133Mhz 2400Mhz 2933Mhz 3200Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
Audio Chipset	Realtek ALC1220
Audio Channels	2/4/5.1/7.1-channel Support for S/PDIF Out
LAN Chipset	Realtek GbE LAN chip
Max LAN Speed	10/100/1000Mbps
SLI Support	No
CrossFire Support	No
RAID Support	Yes
Back Connect	No
Wireless LAN	Yes
Wi-Fi Generation	5
PCI-Express x16 Slots	1
PCI-Express x4 Slots	0
PCI-Express x1 Slots	0
SATA 6 Gbps Ports	4
SATA Express Ports	0
M.2 Ports	1
M.2 Devices support	2260 / 2280 - M Key
RAM Slots	2
Maximum Supported RAM	32 GB
Onboard USB 2.0	1
Onboard USB 3.2 Gen 1	1
Onboard USB 3.2 Gen 2	0
Onboard USB 3.2 Gen 2x2	0

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C
