Gigabyte GA-B250M-DS3H Motherboard

Name: Gigabyte GA-B250M-DS3H
Brand: Gigabyte
SKU: GA-B250M-DS3H
Rating: 3.0 (34 reviews)

GIGABYTE GA-B250M-DS3H LGA1151 Micro ATX DDR4

★★★☆☆

(34 reviews)

Seller	Availability	Price	Shipping	Buy
In Stock	In Stock	$134.51 +Free shipping	+Free	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.

Supports 7th/6th Generation Intel Core Processors.Intel optane memory ready
Dual Channel DDR4, 4DIMMs
Relate ALC887 Codec
Gigabyte UEFI Dual BIOS
Pie Gen3 x4 M.2 Connector with up to 32Gb/s Data Transfer

Specifications Overview

Model	GA-B250M-DS3H
Release Date	January 2017 * First availability for purchase, it may not correspond to the actual market launch date.
Series
Socket	LGA1151
Form factor	Micro ATX
Chipset	Intel B250
Supported Memory	DDR4 2133Mhz 2400Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
Audio Chipset	Realtek ALC887
Audio Channels	2/4/5.1/7.1-channel
LAN Chipset	Realtek GbE LAN chip
Max LAN Speed	10/100/1000Mbps
SLI Support	No
CrossFire Support	No
RAID Support	No
Back Connect	No
Wireless LAN	No
PCI-Express x16 Slots	1
PCI-Express x4 Slots	0
PCI-Express x1 Slots	2
SATA 6 Gbps Ports	6
SATA Express Ports	0
M.2 Ports	1
M.2 Devices support	2242 / 2260 / 2280 - M Key
RAM Slots	4
Maximum Supported RAM	64 GB
Onboard USB 2.0	2
Onboard USB 3.2 Gen 1	1
Onboard USB 3.2 Gen 2	0
Onboard USB 3.2 Gen 2x2	0

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C
