GIGABYTE GA-H110TN-GSM PLUS Motherboard

Name: GIGABYTE GA-H110TN-GSM PLUS
Brand: Gigabyte
SKU: GA-H110N
Rating: 3.0 (8 reviews)

GIGABYTE GA-H110TN-GSM PLUS LGA 1151 DDR4 SO-DIMM

★★★☆☆

(8 reviews)

Seller	Availability	Price	Shipping	Buy
Out of Stock	Out of Stock	$139.99 +Free shipping	+Free	Buy
		-	-	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.

Supports 7Th/6Th Generation Intel Core Processors
Dual Channel DDR4 SO-DIMM, 2 Dimms
2 X RS232/422/485, 2 X RS232, Digital I/O 4-In/4-Out
Mini-Pie Slot For Full/Half-Height WIFI Card Support
Mini-Pie Dual Purpose Slot For Msata SSD Support

Specifications Overview

Model	GA-H110N GA-H110N (rev. 1.0)
Release Date	February 2017 * First availability for purchase, it may not correspond to the actual market launch date.
Socket	LGA1151
Form factor	Mini ITX
Chipset	Intel H110
Supported Memory	DDR4 2133Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
Audio Chipset	Realtek ALC887
Audio Channels	7.1 Channels
LAN Chipset	Realtek GbE LAN chip
Max LAN Speed	10/100/1000Mbps
SLI Support	No
CrossFire Support	No
RAID Support	No
Back Connect	No
Wireless LAN	No
PCI-Express x16 Slots	1
PCI-Express x4 Slots	0
PCI-Express x1 Slots	0
SATA 6 Gbps Ports	3
SATA Express Ports	0
M.2 Ports	2
M.2 Devices support	2260 / 2280 - M Key 2230 - E Key
RAM Slots	2
Maximum Supported RAM	32 GB
Onboard USB 2.0	1
Onboard USB 3.2 Gen 1	1
Onboard USB 3.2 Gen 2	0
Onboard USB 3.2 Gen 2x2	0

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C
