MSI MAG A1000GL PCIE5 Power Supply

MSI MAG A1000GL PCIE5 1000W 80 PLUS Gold Modular

Seller	Availability	Price	Shipping	Buy
In Stock	In Stock	$134.99	-	Buy
In Stock	In Stock	$138.99 +Free shipping	+Free	Buy
In Stock	In Stock	$138.99 + $3.99 Shipping	+ $3.99	Buy
In Stock	In Stock	$149.99 +Free shipping	+Free	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

MSI - MAG A1000GL PCIE 5, 80 GOLD Fully Modular Gaming PSU, 12V-2×6 Cable, ATX 3.1 & PCIE 5.1 Ready, 1000W Power Supply, 10 Year Warranty Fans: 1 x 135 mm Fluid Dynamic Bearing Input Voltage: 100 - 240 V Input Frequency Range: 50/60 Hz Input Current: 15A (Max.) Output: +5V@22A, +3.3V@22A, +12V@83.3A, -12V@0.3A, +5VSB@3A Dimensions: 11.53 * 9.25 * 5.08' Weight: 7.54 lbs Connectors: 1 x ATX (24 PIN) 2 x EPS (4+4 PIN) 1x PCI-E 5.1 (16 PIN) 4 x PCI-E (6+2 PIN) 12 x SATA (15 PIN) 4 x MOLEX (4 PIN) 1 x Molex to FDD Adapter

Model	MAG A1000GL PCIE5
Wattage	1000 W
Type	ATX
Modular	Full
Efficiency	80+ Gold
PCI-Express 16 Pin 12VHPWR Connectors	1
PCI-Express 12 Pin Connectors	0
PCI-Express 6+2 Pin Connectors	4
PCI-Express 6 Pin Connectors	0
EPS Connectors	2
SATA Connectors	12
Molex Connectors	4
Length	150 mm
