MSI MAG B660M MORTAR WIFI Motherboard

Name: MSI MAG B660M MORTAR WIFI
Brand: MSI
SKU: MAG B660M MORTAR WIFI
Rating: 2.0 (1 reviews)

MSI MAG B660M MORTAR WIFI Micro ATX

★★☆☆☆

(1 reviews)

Seller	Availability	Price	Shipping	Buy
Out of Stock	Out of Stock	$179.99 +Free shipping	+Free	Buy
Out of Stock	Out of Stock	$189.99 +Free shipping	+Free	Buy
Out of Stock	Out of Stock	$453.70 +Free shipping	+Free	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

Supports 12th Gen Intel Core Pentium Celeron processors for LGA 1700 socket
Supports DDR4 Memory
Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop works
2.5G LAN and Intel Wi-Fi Solution: Upgraded network solution for professional and multimedia use. Delivers a secure, stable and fast network connection
Lightning M.2: Running at PCIe Gen 4 maximizes performance for NVMe based SSDs

Model	MAG B660M MORTAR WIFI
Socket	LGA1700
Form factor	Micro ATX
Chipset	Intel B660
Supported Memory	DDR5 4800Mhz 5000Mhz 5200Mhz 5400Mhz 5600Mhz 5800Mhz 6000Mhz 6200Mhz View compatible RAM ► * High clock speeds may require enabling the XMP profile in the motherboard BIOS ** RAM support may also depend on the CPU memory controller
ECC RAM Support	No
Audio Chipset	Realtek ALC1200
Audio Channels	7.1 Channels
LAN Chipset	Realtek 8125BG
Max LAN Speed	10/100/1000/2500Mbps
SLI Support	No
CrossFire Support	Yes
RAID Support	Yes
Back Connect	No
Back I/O Ports	1 x DisplayPort 1 x HDMI 1 x LAN (RJ45) 2 x Antenna Bracket 1 x Optical S/PDIF Out 5 x Audio Jacks 1 x USB 3.2 Gen 2x2 Type-C 3 x USB 3.2 Gen 2 Type-A 4 x USB 2.0/1.1
Wireless LAN	Yes
Wi-Fi Generation	6
PCI-Express x16 Slots	2
PCI-Express x4 Slots	0
PCI-Express x1 Slots	1
SATA 6 Gbps Ports	6
SATA Express Ports	0
M.2 Ports	3
M.2 Devices support	2242 / 2260 / 2280 - M Key 2242 / 2260 / 2280 - M Key 2230 - E Key
RAM Slots	4
Maximum Supported RAM	192 GB
Onboard USB 2.0	2
Onboard USB 3.2 Gen 1	1
Onboard USB 3.2 Gen 2	1
Onboard USB 3.2 Gen 2x2	0

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C
