SAPPHIRE 11267-02-20G Graphics Card

SAPPHIRE AMD Radeon PULSE RX 560 2GD5 2GB GDDR5 HDMI / DVI-D / DP OC (UEFI) 11267-02-20G

Seller	Availability	Price	Shipping	Buy
		-	-	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.

The SAPPHIRE Pulse Radeon RX560 plays your favorites at a smooth 1080p, from the latest eSports games and MOBAs to the most popular, graphically-intensive AAA titles. Built on the future-ready Polaris architecture and sporting 1024 GCN stream processors boost-clocked at 1300MHz. The card is ready for the latest technologies like DisplayPort 1.4 HBR3/HDR , HDMI 4K60, and Freesync 2 technology delivering a high level of graphical fidelity in your faorite games and multimedia experience.

Specifications Overview

Model	11267-02-20G 100413P2GOCL
Release Date	May 2017 * First availability for purchase, it may not correspond to the actual market launch date.
GPU Interface	PCIe x16
GPU Chipset	Radeon RX 560 - 1024
GPU Memory Size	2 GB
GPU Memory Type	GDDR5
GPU Memory Interface	128-bit
GPU Clock Rate	1175 MHz
GPU Boost Clock Rate	1300 MHz
TDP	90 W
Length	210 mm
Cooling Type	1 Fan
Power Connectors	1 PCIe 6-pin
SLI Support	No
CrossFire Support	Yes
DVI-D (Dual Link)	1
DVI-I (Dual Link)	0
DisplayPort	1
HDMI	1
G-SYNC Support	No
FreeSync Support	Yes
Expansion slots required	2

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C

Description

GPU	1024 Stream Processors 14 nm FinFET 4th Graphics Core Next (GCN) 1300 MHz Boost Engine Clock
Memory	128 bit Memory Bus GDDR5 Memory Type 1750 MHz, 7000 MHz Effective 2 GB Size
BIOS Support	UEFI BIOS
Displays	Maximum 3 Outputs
Output	1 x DVI-D 1 x HDMI 1 x DisplayPort 1.4
Resolution	5120×2880 (60Hz) Pixel DisplayPort Resolution 2560x1600 (60Hz) Pixel Dual Link DVI Resolution 4096×2160 (60 Hz) HDMI Resolution
API	OpenGL® 4.5 OpenCL 2.0 DirectX® 12 Shader Model 5.0
Feature	AMD CrossFire FreeSync Technology AMD Eyefinity AMD Xconnect ready DirectX™ 12 Optimized HDR Ready Frame Rate Target Control Precision fan control Radeon Chill Radeon Relive
Cooling	Single fan
Form Factor	2 Part Slot Occupied 210(L)X 112(W)X 36 (H) Dimension /mm
Power Consumption	90W
OS	Windows 10　Windows 7
System Requirement	400 Watt Power Supply (Suggestion) 1 x 6-pin AUX Power Connector CD-ROM or DVD-ROM drive for installing software PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
