V-Color 192GB (8x24GB) DDR5 7000MHz OC R-DIMM RAM

V-Color 192GB (8x24GB) DDR5 7000MHz OC R-DIMM CL34 3Gx8 1Rx8 ECC Registered DIMM 1.4V (AMD Expo) (TRA524G70S834O)

Seller	Availability	Price	Shipping	Buy
Out of Stock	Out of Stock	$1,909.99 +Free shipping	+Free	Buy
		-	-	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.

Options (9)

	192GB (24GBx8) 6800MHz (PC5-54400) Exclusive v-color Micro-Heatsink $1,717.99
	128GB (16GBx8) 6400MHz (PC5-51200) Exclusive v-color Micro-Heatsink $5,099.99
	128GB (16GBx8) 6000MHz (PC5-48000) Exclusive v-color Micro-Heatsink $4,819.99
	128GB (16GBx8) 7000MHz (PC5-56000) Exclusive v-color Micro-Heatsink $5,459.99
	128GB (16GBx8) 6600MHz (PC5-52800) Exclusive v-color Micro-Heatsink $5,219.99
	128GB (16GBx8) 6800MHz (PC5-54400) Exclusive v-color Micro-Heatsink $5,299.99
	192GB (24GBx8) 6400MHz (PC5-51200) Exclusive v-color Micro-Heatsink $1,429.99
	192GB (24GBx8) 5600MHz (PC5-44800) Exclusive v-color Micro-Heatsink $1,237.99
	192GB (24GBx8) 6000MHz (PC5-48000) Exclusive v-color Micro-Heatsink $1,333.99

Compatible with AMD WRX90 Workstation Motherboards. Overclocking E.X.P.O Profile
Product Specification- Memory Type: DDR5 OC R-DIMM (ECC Registered DIMM) | Chip: Hynix IC | Pin: 288 Pin
Memory Capacity: 192GB (24GBx8) | Speed: 7000MHz (PC5-56000) | Latency: CL34 | IC Configuration: 3Gx8 | Rank: 1Rx8
Equipped with new exclusive RCD and PMIC Micro-Heatsink for improved cooling efficiency.
Manufactured in-house with high-quality Hynix ICs, each IC undergoes rigorous testing using auto-sorting equipment designed by V-COLOR
🔺 FOR WORKSTATION MOTHERBOARDS. NOT COMPATIBLE WITH DESKTOP PC AND LAPTOP.
Supports ECC functionality to detect and correct data errors and features a built-in temperature-monitoring thermal sensor to prevent overheating, thereby enhancing memory reliability. Operating temperature range: 0 to 85 °C

V-Color 192GB (8x24GB) DDR5 7000MHz OC R-DIMM image 1

V-Color 192GB (8x24GB) DDR5 7000MHz OC R-DIMM image 2

V-Color 192GB (8x24GB) DDR5 7000MHz OC R-DIMM image 3

Specifications Overview

Model	TRA524G70S834O
Type	288-pin DDR5 DIMM
Speed	DDR5-7000 MHz
Size	192GB (8 x 24GB)
CAS Latency	34
Timing	34-42-42-102
First Word Latency	9.71 ns
Voltage	1.4 V
Heat Spreader	No
ECC Support	Yes

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C

RAM First Word Latency Table (nanoseconds)

Latency is measured in nanoseconds, which is a combination of frequency and CAS. Both frequency increases and latency decreases result in better system performance (when latency is the same, always prefer higher frequency if possible).

Frequency (MT/s)

	5200	5600	6000	6200	6400	6600	6800	7000	7200	7400	7600	7800	8000	8200
28	10.77	10.00	9.33	9.03	8.75	8.48	8.24	8.00	7.78	7.57	7.37	7.18	7.00	6.83
29	11.15	10.36	9.67	9.35	9.06	8.79	8.53	8.29	8.06	7.84	7.63	7.44	7.25	7.07
30	11.54	10.71	10.00	9.68	9.38	9.09	8.82	8.57	8.33	8.11	7.89	7.69	7.50	7.32
31	11.92	11.07	10.33	10.00	9.69	9.39	9.12	8.86	8.61	8.38	8.16	7.95	7.75	7.56
32	12.31	11.43	10.67	10.32	10.00	9.70	9.41	9.14	8.89	8.65	8.42	8.21	8.00	7.80
33	12.69	11.79	11.00	10.65	10.31	10.00	9.71	9.43	9.17	8.92	8.68	8.46	8.25	8.05
34	13.08	12.14	11.33	10.97	10.63	10.30	10.00	9.71	9.44	9.19	8.95	8.72	8.50	8.29
35	13.46	12.50	11.67	11.29	10.94	10.61	10.29	10.00	9.72	9.46	9.21	8.97	8.75	8.54
36	13.85	12.86	12.00	11.61	11.25	10.91	10.59	10.29	10.00	9.73	9.47	9.23	9.00	8.78
37	14.23	13.21	12.33	11.94	11.56	11.21	10.88	10.57	10.28	10.00	9.74	9.49	9.25	9.02
38	14.62	13.57	12.67	12.26	11.88	11.52	11.18	10.86	10.56	10.27	10.00	9.74	9.50	9.27
39	15.00	13.93	13.00	12.58	12.19	11.82	11.47	11.14	10.83	10.54	10.26	10.00	9.75	9.51
40	15.38	14.29	13.33	12.90	12.50	12.12	11.76	11.43	11.11	10.81	10.53	10.26	10.00	9.76
41	15.77	14.64	13.67	13.23	12.81	12.42	12.06	11.71	11.39	11.08	10.79	10.51	10.25	10.00
42	16.15	15.00	14.00	13.55	13.13	12.73	12.35	12.00	11.67	11.35	11.05	10.77	10.50	10.24
43	16.54	15.36	14.33	13.87	13.44	13.03	12.65	12.29	11.94	11.62	11.32	11.03	10.75	10.49
44	16.92	15.71	14.67	14.19	13.75	13.33	12.94	12.57	12.22	11.89	11.58	11.28	11.00	10.73
45	17.31	16.07	15.00	14.52	14.06	13.64	13.24	12.86	12.50	12.16	11.84	11.54	11.25	10.98
46	17.69	16.43	15.33	14.84	14.38	13.94	13.53	13.14	12.78	12.43	12.11	11.79	11.50	11.22
47	18.08	16.79	15.67	15.16	14.69	14.24	13.82	13.43	13.06	12.70	12.37	12.05	11.75	11.46
48	18.46	17.14	16.00	15.48	15.00	14.55	14.12	13.71	13.33	12.97	12.63	12.31	12.00	11.71
49	18.85	17.50	16.33	15.81	15.31	14.85	14.41	14.00	13.61	13.24	12.89	12.56	12.25	11.95
50	19.23	17.86	16.67	16.13	15.63	15.15	14.71	14.29	13.89	13.51	13.16	12.82	12.50	12.20
51	19.62	18.21	17.00	16.45	15.94	15.45	15.00	14.57	14.17	13.78	13.42	13.08	12.75	12.44
52	20.00	18.57	17.33	16.77	16.25	15.76	15.29	14.86	14.44	14.05	13.68	13.33	13.00	12.68

CAS (clock cycles) Lower latency means faster memory.

Distribution of First Word Latencies for Similar RAM Modules

The histogram below shows the distribution of first word latencies (in nanoseconds) for all RAM modules of the same DDR type and frequency in our database. Each bar represents the number of modules that fall within a specific latency range. The highlighted bar indicates the latency of the currently selected RAM module.
