V-Color TE524G64S832SKK 48GB (2x24GB) DDR5 6400MHz RAM

V-Color TE524G64S832SKK 48GB (2x24GB) DDR5 6400MHz CL32 1Rx8 OC ECC UNBUFFERED DIMM 1.4V

Seller	Availability	Price	Shipping	Buy
Out of Stock	Out of Stock	$449.99 + $35.00 Shipping	+ $35.00	Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

Product Specification: DDR5 OC ECC U-DIMM ( Overclocking ECC Unbuffered DIMM) Pin: 288 Pin Memory Capacity: 96GB (48GBx2) Speed: 6400MHz (PC5-51200) Latency: CL32 IC Configuration: 3Gx8 Rank: 2Rx8 Equipped with premium Hynix ICs, each module is rigorously tested using advanced auto-sorting equipment designed by v-color to ensure stable and reliable performance.

V-Color TE524G64S832SKK 48GB (2x24GB) DDR5 6400MHz image 1

Specifications Overview

Model	TE524G64S832SKK
Type	288-pin DDR5 DIMM
Speed	DDR5-6400 MHz
Size	48GB (2 x 24GB)
CAS Latency	32
Timing	32-39-39-102
First Word Latency	10 ns
Voltage	1.4 V
Heat Spreader	Yes
ECC Support	Yes

	Old Name	Current Name	Branding	Data Speed	Port
USB 2.0	USB 2.0	USB 2.0	Hi-Speed USB	480 Mbit/s	diverse
USB 3.0	USB 3.1 Gen 1	USB 3.2 Gen 1x1	SuperSpeed USB	5 Gbit/s	diverse
USB 3.1	USB 3.1 Gen 2	USB 3.2 Gen 2x1	SuperSpeed USB 10Gbps	10 Gbit/s	diverse
USB 3.2	USB 3.2 Gen 2x2	USB 4.0 Gen 2x2	USB4 20Gbps	20 Gbit/s	only USB-C
USB4	USB 4.0 Gen 3x2	USB4 1.0	USB4 40Gbps	40 Gbit/s	only USB-C
USB4v2	USB 4.0 Gen 4	USB4 2.0	USB4 80Gbps	80-120 Gbit/s	only USB-C

RAM First Word Latency Table (nanoseconds)

Latency is measured in nanoseconds, which is a combination of frequency and CAS. Both frequency increases and latency decreases result in better system performance (when latency is the same, always prefer higher frequency if possible).

Frequency (MT/s)

	4400	4800	5000	5200	5600	6000	6200	6400	6600	6800	7000	7200	7400	7600
32	14.55	13.33	12.80	12.31	11.43	10.67	10.32	10.00	9.70	9.41	9.14	8.89	8.65	8.42
33	15.00	13.75	13.20	12.69	11.79	11.00	10.65	10.31	10.00	9.71	9.43	9.17	8.92	8.68
34	15.45	14.17	13.60	13.08	12.14	11.33	10.97	10.63	10.30	10.00	9.71	9.44	9.19	8.95
35	15.91	14.58	14.00	13.46	12.50	11.67	11.29	10.94	10.61	10.29	10.00	9.72	9.46	9.21
36	16.36	15.00	14.40	13.85	12.86	12.00	11.61	11.25	10.91	10.59	10.29	10.00	9.73	9.47
37	16.82	15.42	14.80	14.23	13.21	12.33	11.94	11.56	11.21	10.88	10.57	10.28	10.00	9.74
38	17.27	15.83	15.20	14.62	13.57	12.67	12.26	11.88	11.52	11.18	10.86	10.56	10.27	10.00
39	17.73	16.25	15.60	15.00	13.93	13.00	12.58	12.19	11.82	11.47	11.14	10.83	10.54	10.26
40	18.18	16.67	16.00	15.38	14.29	13.33	12.90	12.50	12.12	11.76	11.43	11.11	10.81	10.53
41	18.64	17.08	16.40	15.77	14.64	13.67	13.23	12.81	12.42	12.06	11.71	11.39	11.08	10.79
42	19.09	17.50	16.80	16.15	15.00	14.00	13.55	13.13	12.73	12.35	12.00	11.67	11.35	11.05
43	19.55	17.92	17.20	16.54	15.36	14.33	13.87	13.44	13.03	12.65	12.29	11.94	11.62	11.32
44	20.00	18.33	17.60	16.92	15.71	14.67	14.19	13.75	13.33	12.94	12.57	12.22	11.89	11.58
45	20.45	18.75	18.00	17.31	16.07	15.00	14.52	14.06	13.64	13.24	12.86	12.50	12.16	11.84
46	20.91	19.17	18.40	17.69	16.43	15.33	14.84	14.38	13.94	13.53	13.14	12.78	12.43	12.11
47	21.36	19.58	18.80	18.08	16.79	15.67	15.16	14.69	14.24	13.82	13.43	13.06	12.70	12.37
48	21.82	20.00	19.20	18.46	17.14	16.00	15.48	15.00	14.55	14.12	13.71	13.33	12.97	12.63
49	22.27	20.42	19.60	18.85	17.50	16.33	15.81	15.31	14.85	14.41	14.00	13.61	13.24	12.89
50	22.73	20.83	20.00	19.23	17.86	16.67	16.13	15.63	15.15	14.71	14.29	13.89	13.51	13.16
51	23.18	21.25	20.40	19.62	18.21	17.00	16.45	15.94	15.45	15.00	14.57	14.17	13.78	13.42
52	23.64	21.67	20.80	20.00	18.57	17.33	16.77	16.25	15.76	15.29	14.86	14.44	14.05	13.68

CAS (clock cycles) Lower latency means faster memory.

Distribution of First Word Latencies for Similar RAM Modules

The histogram below shows the distribution of first word latencies (in nanoseconds) for all RAM modules of the same DDR type and frequency in our database. Each bar represents the number of modules that fall within a specific latency range. The highlighted bar indicates the latency of the currently selected RAM module.
