XFX TS Gold Series 650W

XFX TS Gold Series 650W 80 PLUS Gold P1-650G-TS3X

XFX TS Gold Series 650W 80 PLUS Gold P1-650G-TS3X

★★★★★
(221 reviews)
Seller Price Buy
-
Buy

* Pangoly may earn a commission when you use one of the links to make a purchase. (Disclosure)

* Product prices and availability are subject to change frequently. Any price and availability information displayed on Amazon at the time of purchase will apply.
Price Alert

$

Price alerts are not available for Amazon.

  • The XFX TS Series 650W is an 80 Plus Gold certified PSU that combines great performance, innovative design, and the high quality required by hardcore gamers and DIY enthusiasts. Advanced EasyRail technology allows you to run power-hungry components, such as a CPU and GPU, without worrying about individual rail limits. The hybrid fan delivers effective cooling noiselessly. Enjoy first-class reliability and stability with 105C Japanese capacitors.

Specifications Overview

Model P1-650G-TS3X
Release Date September 2018

* First availability for purchase, it may not correspond to the actual market launch date.

Wattage 650 W
Type ATX
Modular No
Efficiency 80+ Gold
Output 0.3A@-12V, 54A@+12V, 20A@+3.3V, 20A@+5V, 2.5A@+5VSB
PCI-Express 16 Pin 12VHPWR Connectors 0
PCI-Express 12 Pin Connectors 0
PCI-Express 6+2 Pin Connectors 4
PCI-Express 6 Pin Connectors 0
EPS Connectors 2
SATA Connectors 10
Molex Connectors 4
Length 160 mm

Description

General

+12V Rail Outputs : Single

100% Tested and Verified : Y

ATX12V 2.2 & ESP12V 2.91 Compliant : Y

ATX12V 2.31 Compliant : Y

Compatible with intel ad AMD platforms : Y

UPC Number : 778656065536



Technologies

CrossFire Ready : Y

Hasewell Ready : Y

SLI Ready : Y



Ratings & Efficiencies

AC Input Current (Arms) : 9A-4.5A

AC Input Frequency (Hz) : 50/60 Hz

AC Input Voltage (Vac) : 100-240 VAC

Efficiency @ Typical Load : Up to 90%

Energy-Efficiency : 80 Plus Gold Certified

Maximum Wattage : 650 Watts



Other Features

High Reliable 105°C Japanese Capacitors : Y

Solid State Capacitors : Y

Tight voltage regulation (±5%) : Y



Load Range

Max -12V Output Current (A) : 0.3

Max +12V Output Current (A) : 54

Max +3.3V Output Current (A) : 20

Max +5V Output Current (A) : 20

Max +5VSB Output Current (A) : 2.5

Cable Connectors

Fixed FDD : One Connectors

Fixed Peripheral : Up to 4 Connectors

Fixed 6-pin PCI-E : 4

Fixed ATX12V / EPS12V : One 4+4-pin, One EPS 12V 8-pin

Fixed Motherboard Connector : 20+4-Pin

Fixed SATA : Up to 10 Connectors



Safety & Protection

Active Power Factor Correction (PFC) : Y

Over Current Protection (OCP) : Y

Over Power Protection (OPP) : Y

Over Temperature Protection : Y

Over Voltage Protection (OVP) : Y

Short Circuit Protection (SCP) : Y

Under Voltage Protection (UVP) : Y



Physical

Cooling Fan Size (mm) : 120mm FDB (Fluid Dynamic Bearing) Fan (Black)

Master Carton Dimensions (cm) : 43.1 x 30.7 x 33.1

Master Carton Dimensions (inch) : 16.96 x 12.08 x 13.03

Master Carton Weight (Kg) : 17.26

Master Carton Weight (lb) : 38.05

Package Dimensions (cm) : 31 x 20 x 9.5

Package Dimensions (inch) : 12.2 x 7.87 x 3.74

Package Weight (Kg) : 2.76

Package Weight (lb) : 6.08

Product Dimensions (cm) : 14 x 16 x 8.6

Product Dimensions (inch) : 5.5 x 5.9 x 3.38

Product Net Weight (Kg) : 2

Product Net Weight (lb) : 4.41



Includes

AC Power Cord : 1

Units/Carton : 6

User's Manual : 1
