MSI PRO B840-S EVO WIFI6E AM5 DDR5 8000+ MT/s OC PCIe 4.0 x16 M.2 Gen4 Wi-Fi 6E 2.5G LAN ATX

MSI PRO B840-S EVO WIFI6E AM5 DDR5 8000+ MT/s OC PCIe 4.0 x16 M.2 Gen4 Wi-Fi 6E 2.5G LAN ATX

Venditore Prezzo Compra
Disponibile
€164,26
Prime
Compra
Ultimo aggiornamento 52 minuti fa.

* Pangoly potrebbe guadagnare una commissione quando utilizzi uno dei link per effettuare un acquisto. (Disclosure)

* I prezzi dei prodotti e la disponibilità sono soggetti a modifiche frequenti. Verranno applicate tutte le informazioni su prezzi e disponibilità visualizzate su Amazon al momento dell'acquisto.
Avviso cambio di prezzo

Gli alert di prezzo non sono disponibili per Amazon.

  • ULTRA POWER - SUPPORTS THE RYZEN 9000 PROCESSORS IN HIGH PERFORMANCE - The PRO B840-S EVO WIFI6E employs a Direct 7 Phase (P-PAK) VRM for the AMD B840 chipset (AM5, Ryzen 9000 / 8000 / 7000) with MSI Core Boost technology for improved performance
  • FROZR GUARD - Excellent cooling features such as 7W/mK MOSFET thermal pads; Includes chipset heatsink, M.2 Shield Frozr, a Combo-fan (for pump & system) header (3A)
  • DDR5 MEMORY, PCIe 4.0 x16 SLOTS - 4 x DDR5 DIMM slots enable extreme memory overclocking speeds (1DPC 1R, up to 8000+ MT/s OC); 1 x PCIe 4.0 x16 slot (64GB/s) with Steel Armor supports cutting-edge graphics cards
  • DOUBLE M.2 GEN4 CONNECTORS - Storage options include 2 x M.2 Gen4 x4 64Gbps slots; The primary M.2 slot includes M.2 Shield Frozr to prevent thermal throttling during hyper-fast SSD access
  • HIGH-SPEED CONNECTIVITY - Network hardware includes a Wi-Fi 6E module with Bluetooth 5.3 & 2.5Gbps LAN; Rear ports include USB 10Gbps Type-C and 7.1 HD Audio with Audio Boost

Scheda tecnica

Modello
  • PRO B840-S EVO WIFI6E
  • 7E93-001R
Disponibile da Gennaio 2026

* Prima data di disponibilità per l'acquisto, potrebbe non necessariamente corrispondere a quando il prodotto è stato lanciato sul mercato.

Socket AM5
Formato ATX
Chipset AMD B840
Memoria Supportata DDR5
4800Mhz 5200Mhz 5600Mhz 8000Mhz
* Le velocità di clock più elevate potrebbero richiedere l'abilitazione del profilo XMP nel BIOS della scheda madre
** Il supporto per la compatibilità delle RAM potrebbe dipendere anche dal controller di memoria della CPU
Supporto RAM ECC No
Supporto SLI No
Supporto CrossFire No
Supporto RAID
Back Connect No
Wireless LAN
Generazione Wi-Fi 6E
Slot PCI-Express x16 2
Slot PCI-Express x4 0
Slot PCI-Express x1 0
Porte SATA 6 Gbps 4
Porte SATA Express 0
Porte M.2 3
Supporto dispositivi M.2
  • 2260 / 2280 - M Key
  • 2260 / 2280 / 22110 - M Key
  • 2260 / 2280 - M Key
Slot RAM 4
RAM Massima Supportata 256 GB
Connettori USB 2.0 2
Connettori USB 3.2 Gen 1 1
Connettori USB 3.2 Gen 2 1
Connettori USB 3.2 Gen 2x2 0
