Display
Display Size (in.)
23
Viewable Area (in.)
23
Panel Type
IPS
Resolution
1920 x 1080
Static Contrast Ratio
1,000:1
Dynamic Contrast Ratio
80M:1
Light Source
LED
Brightness
250 cd/m2
Colors
16.7M
Response Time (Typical GTG)
7ms
Viewing Angles
178º horizontal, 178º vertical
Backlight Life (Hours)
30,000
Panel Surface
Anti-glare, hard-coating (3H)
Compatibility
PC Resolution (max)
Up to 1920x1080 non-interlaced
Mac® Resolution (max)
Up to 1920x1080
Connector
3.5mm Audio In
1
3.5mm Audio Out
1
HDMI
1
VGA
1
Display Port
1
Power in
External Power Adapter
Audio
Internal Speakers
3-watt (x2)
Power
Eco Mode (Conserve)
17W
Eco Mode (optimized)
20W
Consumption (typical)
23W
Consumption (max)
32W
Voltage
AC 100-240V (universal), 50-60Hz
Additional Hardware
Kensington Lock Slot
1
Controls
Physical Controls
GameMode, 1, 2, 3, 4, Power
On Screen Display
Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Advanced Image Adjust, Setup Menu, Memory Recall (See user guide for complete OSD functionality)
Operating Conditions
Temperature
32-104º F (0–40º C)
Humidity (non-condensing)
20-90%
Video Signal
Frequency Horizontal
24~82kHz
Frequency Vertical
50~75Hz
Video Input
Analog Sync
Separate Sync, TMDS, PCI-E
Weight (imperial)
Net (lbs)
5.7
Gross (lbs)
8.8
Weight (metric)
Net (kg)
2.6
Gross (kg)
4.0
Dimensions (imperial) (wxhxd)
Packaging (in.)
23.4 x 15.8 x 4.5
Physical (in.)
20.9 x 16.2 x 8.2
Dimensions (metric) (wxhxd)
Packaging (mm)
595 x 400 x 115
Physical (mm)
531 x 410.9 x 209
General
Regulations
CE EMC, CB, RoHS BOM & RoHS DoC, ErP, REACH SVHC List & DoC, WEEE, EEL, cULus, FCC-B, DOE ENERGY STAR 6.0, DOE EPEAT (Silver), NRCan, UL-MX-CoC, Mexico Energy
PACKAGE CONTENTS
VX2376-smhd monitor, Power cable, AC/DC adapter, Audio cable, VGA cable, HDMI cable, Quick Start Guide, ViewSonic Wizard CD
Recycle/Disposal
Please dispose of in accordance with local, state or federal laws.
Warranty
Three-year limited warranty on parts, labor and backlight
