General
+12V Rail Outputs : Single
100% Tested and Verified : Y
ATX12V 2.2 & ESP12V 2.91 Compliant : Y
ATX12V 2.31 Compliant : Y
Compatible with intel ad AMD platforms : Y
UPC Number :
Technologies
CrossFire Ready : Y
Hasewell Ready : Y
SLI Ready : Y
Ratings & Efficiencies
AC Input Current (Arms) : 9A-4.5A
AC Input Frequency (Hz) : 50/60 Hz
AC Input Voltage (Vac) : 100-240 VAC
Efficiency @ Typical Load : Up to 85%
Energy-Efficiency : 80 Plus Bronze Certified
Maximum Wattage : 430 Watts
Other Features
High Reliable 105°C Japanese Capacitors : Y
Solid State Capacitors : Y
Tight voltage regulation (±5%) : Y
Load Range
Max -12V Output Current (A) : 0.3
Max -12V Output (W): 3.6
Max +12V Output Current (A) : 33
Max +12V Output (W) : 396
Max +3.3V Output Current (A) : 20
Max +5V Output Current (A) : 20
Max +3.3V and +5V Output (W) : 82
Max +5VSB Output Current (A) : 2.5
Max +5VSB Output (W) : 10
Cable Connectors
Fixed FDD : One Connectors
Fixed (Molex): 2 (Triple Molex Cables)
Fixed PCI-E Connectors : 1x 6+2-pin
Fixed ATX12V / EPS12V : One 4+4-pin, One EPS 12V 8-pin
Fixed Motherboard Connector : 20+4-Pin
Fixed SATA : Up to 3 Connectors (3 Triple SATA Cables)
Safety & Protection
Active Power Factor Correction (PFC) : Y
Over Current Protection (OCP) : Y
Over Power Protection (OPP) : Y
Over Temperature Protection : Y
Over Voltage Protection (OVP) : Y
Short Circuit Protection (SCP) : Y
Under Voltage Protection (UVP) : Y
Physical
Cooling Fan Size (mm) : 120mm Hypro Bearing Fan (Black)
Master Carton Dimensions (cm) : 30.7 cm W x43.1 cm H x 33.1 cm D
Master Carton Dimensions (inch) : 12.09
Master Carton Weight (Kg) : 16.56 kg est.
Master Carton Weight (lb) : 36.48 lbs est.
Package Dimensions (cm) : 26.7 cm W x 20.9 cm H x 13.3cm D
Package Dimensions (inch) : 10.5
Package Weight (Kg) : 2.76 kg est.
Package Weight (lb) : 6.08 lbs est.
Includes
AC Power Cord : 1
Units/Carton : 6
User's Manual : 1
